Drive, AC, 20HP, 480V, 27.0A, VT N1
MFG Item Number ACH580-VCR-027A-4+F267
Drive, AC, 20HP, 480V, 27.0A, VT N1
Drive, AC, 20HP, 480V, 27.0A, VT N1 ACH580-VCR-027A-4+F267Drive, AC, 20HP, 480V, 27.0A, VT N1Drive, AC, 20HP, 480V, 27.0A, VT N1
The ACH580 drive sets new standards in both simplicity and reliability, and ensures smooth, energy‑efficient operation of your HVAC systems in normal and mission‑critical situations. ACH580 drives come with a range of advanced features, such as a new primary settings menu that makes commissioning the drives much easier and faster. Optional Bluetooth connectivity offers improved accessibility for drives in remote areas and increases safety by letting users stay out of arc flash zones. ACH580 drives are ideal for HVAC fans, pumps, compressors, air‑handling units, and chillers. These are used in hospitals, data centers, shopping centers, tunnel ventilation, factories, office buildings, and more.
Drive, AC, 20HP, 480V, 27.0A, VT N1 ACH580-VCR-027A-4+F267Drive, AC, 20HP, 480V, 27.0A, VT N1Drive, AC, 20HP, 480V, 27.0A, VT N1
Description
HVAC Drives, ACH580 Series
Item #
ACH580-VCR-027A-4+F267
Drive, AC, 20HP, 480V, 27.0A, VT N1
ACH580 Series Information
- AC Drive for HVAC
- Wall‑Mounted
- User Friendly Control Panel
- User‑Friendly Control Panel with Bluetooth Option
- Versatile for HVAC Applications
- Programmed Protection Circuits
- HVAC Communication Protocols
- BACnet MS/TP, Johnson Controls N2, and Modbus RTU
- Built‑in PID Controllers
The ACH580 drive sets new standards in both simplicity and reliability, and ensures smooth, energy‑efficient operation of your HVAC systems in normal and mission‑critical situations. ACH580 drives come with a range of advanced features, such as a new primary settings menu that makes commissioning the drives much easier and faster. Optional Bluetooth connectivity offers improved accessibility for drives in remote areas and increases safety by letting users stay out of arc flash zones. ACH580 drives are ideal for HVAC fans, pumps, compressors, air‑handling units, and chillers. These are used in hospitals, data centers, shopping centers, tunnel ventilation, factories, office buildings, and more.
Specifications
| In Stock | No |
|---|---|
| Ships Factory Direct | No |
| Manufacturer Part Number | ACH580-VCR-027A-4+F267 |
| Manufacturer | ABB |
| Product Series | ACH580 |
| Family Series | ABB HVAC Drives, ACH580 Series |
| Description | Drive, AC, 20HP, 480V, 27.0A, VT N1 ACH580-VCR-027A-4+F267 |
| Bypass Type | Electronic |
| Disconnect Type | Circuit Breaker |
| Nominal Input Voltage | 480 VAC |
| Phase | 3 |
| HP (Variable Torque Rating) | 20 hp |
| Amps (Variable Torque Rating) | 27 A |
| Brake | Dynamic Braking, Flux Braking |
| Closed Loop | No |
| AC Line Regenerative | No |
| Frequency | 500 Hz |
| AC Voltage | 380-480 VAC |
| Operator Controls | Keypad Included |
| Motor Control-Max Level | Open Loop Vector (Sensorless Vector) |
| Mounting | Panel |
| Frame Size | VX1-3 |
| IP Rating | IP21 |
| NEMA Rating | NEMA 1 |
| Comments | Circuit Breaker, Electronic Bypass, Built-in BACnet MS/TP, N2 & Modbus RTU |
| Height | 47.7 " |
| Width | 8.44 " |
| Depth | 10.9 " |
| Net Weight | 59.5 lbs |
| Gross Weight | 0 lbs |
